KMG SBC 90 is a low density device of the B2BUA type for small scenarios. It has the capacity to perform up to 300 SIP sections or up to 90 calls with transcoding, it has powerful signal processors for converting media and protocols between networks. The SBC 90 guarantees a secure connection between the local network and the VoIP oprator and also includes the VoIP operator and also includes the external telephony modules, with the GSM, E1/T1, FXO and/or FXS technologies, as long as the maximum limit of 60 is respected. STFC telephony channels.
It's an ideal device for call centers and professionals that provide small services that need complete administration of the IP telephony operation with advanced resources.
Key features
Modular composition: up to 8 telephony modules to integrate with the technologies: E1/T1, FXO, FXS and / or GSM.
SBC inegrated: up to 300 SBC VoIP sections in bridge mode; up to 60 SBC VoIP calls with transcoding
Compatibility with call classification
It allows for number portability consultation
TDM Digital - of 1 or 2 E1/T1 (ISDN, R2 and ISUP, in modules of 4 E1/T1)
IP - 2 SIP channels for each E1/T1 (G.711)
SS7 y SIGTRAN (optional license)
G.711 A-law and u-law, native in the system, for all interfaces
G.729a, GSM, DVI, T-38; only with transcoding
Standard 1U center module for 19-inch rack
QoS: DiffServ - RFC 4594 | VLAN Tagging
3 gigabit network interfaces (100/1000 Mbps), one dedicated to high availability
Power supply: Input: 110-220V CA - 50-60Hz | Maximum power consumption: 120W
Gigabit3 Gigabit network ports 100/1000 Mbps
Power supplyInput: 100-240 V 56/60 Hz | Output: 12V / 2.5A
Additional featuresUp to 300 SBC VoIP sections in bridge mode
Supported codecsG.711 A-law and u-law,G.729a annex B, GSM, DVI, T-38; only with transcoding
Ethernet Ports3 gigabit network ports, one of them specific for high availability
GSM portsOptional
PRI portsModular composition: 2 external telephony modules to integrate with E1 / t1, GSM, FXO and / or FXS technologies
